Home /Products/Temperature And Humidity Controller/Temi560 5-inch Color Touch Screen Temperature and Humidity Controller with 120 Program Groups and Fault SMS Alarm System

Temi560 5-inch Color Touch Screen Temperature and Humidity Controller with 120 Program Groups and Fault SMS Alarm System

1
MOQ
Negotiable
Price
Temi560 5-inch Color Touch Screen Temperature and Humidity Controller with 120 Program Groups and Fault SMS Alarm System
Features Gallery Product Description Chat Now
Features
Specifications
Model NO.: TEMI560
Warranty: 1 Year
Custom Service: OEM,ODM
Size Service: Support Customer Customization
Temperature Range: -90~200℃, Error ± 0.2 ℃
Humidity Range: 1%~100%, Error ± 1%
Sensor Type: PT100 Sensor Input (Optional Electronic Sensor);
Control Method: Fixed Value/program
Highlight:

5-inch touch screen temperature controller

,

humidity controller with SMS alarm

,

programmable temperature humidity controller
Basic Infomation
Place of Origin: CHINA
Brand Name: YOUBI
Certification: CE, ISO
Model Number: TEMI560
Payment & Shipping Terms
Packaging Details: Professional export packaging
Delivery Time: 5~10 work days
Payment Terms: D/P,T/T,Western Union
Supply Ability: 20 Unit/month
Product Description
Temi560 Visualized Stable Temperature and Humidity Controller With Convenient Data Processing
Product Overview

The Temi560 is a high-precision temperature and humidity controller featuring a 5-inch color touch screen with TFT resolution of 480 × 272. Utilizing advanced PID temperature control technology, it ensures accurate temperature regulation with minimal fluctuations. The menu-style operation interface is intuitive and user-friendly, making complex experimental processes easily manageable.

  • 120 program groups with up to 100 segments per program
  • Each segment supports run times up to 99 hours and 99 minutes
  • Fault SMS alarm system for enhanced safety
  • Comprehensive data processing capabilities with printer/computer connectivity
  • Dual language support: Chinese and English
Technical Specifications
Parameter Specification
Display 5-inch color touch screen; TFT resolution: 480 × 272
Control Method Fixed value/Program
Sensor Type PT100 sensor input (optional electronic sensor)
Temperature Range -90.0°C to 200.0°C (customizable to -90°C to 300°C), error ±0.2°C
Humidity Range 1% to 100% RH, error ±1%
Input Type Run/Stop, 8 DI failure input; Contact capacity: maximum 12V DC/10mA
Control Output Voltage pulse (SSR); 2 outputs (temperature/humidity)
Settlement Output 8 contact points; Contact capacity: maximum 30V DC/5A, 250V AC/5A
Communication RS232/RS485 interface; Maximum communication distance: 1.2km
Program Capacity 120 program groups, maximum 100 segments per program
Power Supply Touch screen: DC 24V; Lower machine: 85-265V AC, 50/60Hz
Insulation Level 2000V AC/1 minute
Product Images
Temi560 5-inch Color Touch Screen Temperature and Humidity Controller with 120 Program Groups and Fault SMS Alarm System 0 Temi560 5-inch Color Touch Screen Temperature and Humidity Controller with 120 Program Groups and Fault SMS Alarm System 1 Temi560 5-inch Color Touch Screen Temperature and Humidity Controller with 120 Program Groups and Fault SMS Alarm System 2 Temi560 5-inch Color Touch Screen Temperature and Humidity Controller with 120 Program Groups and Fault SMS Alarm System 3 Temi560 5-inch Color Touch Screen Temperature and Humidity Controller with 120 Program Groups and Fault SMS Alarm System 4 Temi560 5-inch Color Touch Screen Temperature and Humidity Controller with 120 Program Groups and Fault SMS Alarm System 5 Temi560 5-inch Color Touch Screen Temperature and Humidity Controller with 120 Program Groups and Fault SMS Alarm System 6
Our Service Process
  • Customer Inquiry: Technical consultation and requirement analysis with product recommendations and competitive pricing
  • Customization: Detailed drawings and reference photos for customized solutions with final pricing confirmation
  • Production & Delivery: Quality-controlled manufacturing with progress updates, calibration services, and timely delivery
  • Installation & Support: Professional installation services and comprehensive after-sales support
Frequently Asked Questions
Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
Yes, we are a professional manufacturer of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment. Every machine includes a 12-month warranty after shipment, with free maintenance during this period. We extend this to 14 months to account for sea transportation. For technical support, contact us via email or phone - we provide solutions within 24-48 hours after problem confirmation.
What about the delivery term?
Standard machines in stock: 3-7 working days
Out-of-stock items: 15-20 working days after payment
Urgent requirements receive special priority arrangements
Do you accept customization services? Can I have my logo on the machine?
Yes, we offer both standard and customized machines according to your specific requirements. We provide OEM and ODM services, including custom branding with your logo.
How can I install and use the machine?
We provide comprehensive English operation manuals and videos via email. Most machines are shipped fully assembled - simply connect the power cable to begin operation. On-site installation assistance is available when necessary.
