High Precision Safety Shoe Impact Tester , Footwear Testing Equipment

Large Image : High Precision Safety Shoe Impact Tester , Footwear Testing Equipment

Product Details:

Place of Origin:	Guangdong,China(mainland)
Brand Name:	HTI
Certification:	S-953 1870, EN-344, ANSI-Z41, CSA-Z195, ISO8782
Model Number:	TX-509

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiation
Packaging Details:	Plywood box package/Woolen package
Delivery Time:	30 days
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	10 sets per month

Contact Now

Detailed Product Description

Drop Hammer Weight:	(EN)20±0.2KG, (BS,ANSI)22.7KG	Height:	(EN)0-1100MM
Impact Energy:	(EN)200 J, (BS,ANSI)100±2J	Impact Blade Ring:	(EN)3±0.1mm R, (ANSI)25.4 Mm
Motor:	DC1/4HP	Dimension(WDH):	MainUnit:58.5×69.5×181.5cm
Velcocity Indicator:	21.5×19×12.6cm	Weight:	227KG
Power:	3∮ AC 380V
Highlight:	Shoe Testing Machine , Shoes Tester

High Precision Safety Shoe Impact Tester , Footwear Testing Equipment

Description:

Safety Shoe Impact Tester comply with EN, ANSI, BS, CSA regulations. Impacting the the steel toe

caps of satety shoes through 100J or 200J power, then observe the sinkage to value its quality. The

design is different among EN, ANSI, BS, CSA, so please prescribe the regulation when ordering.

Specifications:

Drop hammer Weight: (EN)20±0.2KG, (BS,ANSI)22.7KG
Height: (EN)0-1100MM
Impact Energy: (EN)200 J, (BS,ANSI)100±2J
Impact Blade Ring: (EN)3±0.1mm R, (ANSI)25.4 mm
Motor: DC1/4HP
Dimension(W*D*H):MainUnit:58.5×69.5×181.5cm,
Velcocity Indicator:21.5×19×12.6cm
Weight: 227KG
Power: 3∮ AC 380V

Advantages:

1. Speciality in testing equipment

2. Various products to choose from

3. Accept customization

4. Excellent after-sale service

Standards:

BS-953 1870, EN-344, ANSI-Z41, CSA-Z195, ISO8782

Tag:

Contact Person: linmei

Tel: 86-13421721188

Fax: 86-769-23010667
