Name: UP-6114 Low Pressure High Altitude Simulation Chamber , Environmental Climatic Test Chamber
Brand: Dongguan Youbi Test Equipment Co.,Ltd
SKU: UP-6114
Availability: InStock

Features Gallery Product Description Chat Now

Features

Specifications

Product Name: High Altitude Simulation Chamber

Model NO.: UP-6114

Temperature Range: -160ºC~500ºC

Humidity Range: 20%RH ~98%RH

Temp.fluctuation: ±0.5ºC(Room Pressure)

Temp.accuracy: ±2.0ºC(Room Pressure)

Heating Up Time: ≤60min(+20ºC~+150ºC,RP,No-Load)

Power Supply: AC 3Ψ380V 60/50Hz

Highlight:

UP-6114 High Altitude Simulation Chamber

Low Pressure Environmental Simulation Chamber

Environmental Climatic Test Chamber

Basic Infomation

Place of Origin: CHINA

Brand Name: YOUBI

Certification: CE,ISO

Model Number: UP-6114

Payment & Shipping Terms

Packaging Details: Professional Export Wooden Box Packaging

Delivery Time: 5-15 work days

Payment Terms: T/T,D/P,Western Union,Paypal,Money Gram

Supply Ability: 30 Unit/month

Gallery

UP-6114 Low Pressure High Altitude Simulation Chamber , Environmental Climatic Test Chamber

Product Description

UP-6114 High Altitude Low Pressure Simulation Environmental Climatic Test Chamber

Product Overview

High altitude low pressure simulation test chamber achieves low-pressure sample storage state in a short period of time, automatically controls test cycles, monitors pressure changes throughout the process, and automatically terminates tests.

Technical Specifications

Working Room (L)	150	225	408	800	1000
Inner Chamber Size (mm) W×H×D	500×600×500	500×750×600	600×850×800	1000×1000×800	1000×1000×1000
Exterior Chamber Size (mm) W×H×D	1000×1600×1400	1000×1750×1500	1100×1850×1700	1500×2000×1700	1850×1600×2250
Packaging Volume (CBM)	3	3.5	4.5	5.5	6
Gross Weight (KGs)	320	350	400	600	700

Performance Specifications

Temperature Range: -160°C to +500°C (multiple ranges available)
Humidity Range: 20%RH to 98%RH (options: 10%RH to 98%RH or 5%RH to 98%RH)
Temperature Fluctuation: ±0.5°C (Room pressure)
Temperature Accuracy: ±2.0°C (Room pressure)
Heating Time: ≤60min (+20°C to +150°C, RP, No-Load)
Cooling Time: 45-90min (RP, varies by model)
Pressure Range: Atmospheric pressure to -98KPa, ~133KPa, ~0KPa
Pressure Control Tolerance: ±0.1kPa (≤2kPa), ±5% (2kPa~40kPa), ±2kPa (≥40kPa)
Depressurization Time: 20-50min (varies by model)
Working Environment: Temp: +5°C to +35°C; Humidity: ≤90%RH; Air pressure: 86-106kPa

Construction & Systems

Exterior Chamber Material: Stainless steel plate + powder coated
Inner Chamber Material: SUS#304 stainless steel plate
Insulation Material: PU Fiberglass wool
Air Circulation System: Cooling fan
Heating System: SUS#304 stainless steel high-speed heater
Humidification System: Imported compressor, Tecumseh compressor (or Bizer Compressor), finned type evaporator, air/water-cooling condenser
Dehumidification System: ADP critical dew point cooling/dehumidifying method
Vacuum System: Equipped with vacuum pump
Control System: TEMI880, 990
Power: 8-20 kW (varies by model)
Water Supply: Water temperature: ≤30°C; water pressure: 0.2~0.4MPa; flow rate: ≥10T/h

Standard Components

Specimen holders: 2 pcs
Electrical wire: 1 pc (3M)
Pressure testing port

Safety Protection

Over-heat protection circuit breaker
Compressor overload protection
Control system overload protection
Humidifying system overload protection
Overload indicator lamp

Power Supply: AC 3Ψ380V 60/50Hz

Key Features

Temperature range from -70 to 200°C
Altitude range from ground to 100,000 feet
Optional humidity control when altitude system is off
Chamber interior size specified by customer
Automatic altitude control, integrated with temperature controller - No manual setting of altitude level
Vacuum pump sized for climb/dive rate required by application
Viewing window and cable ports available

Product Images

Our Service

During the whole business process, we offer Consultative Selling services:

Customer Inquiry Process: Discuss testing requirements and technical details, suggest suitable products, and provide competitive pricing.
Specifications Customize Process: Create drawings for customized requirements, provide reference photos, and confirm final solution and pricing.
Production and Delivery Process: Manufacture according to confirmed PO requirements, provide production progress photos, conduct calibration, and arrange timely shipping.
Installation and After-Sale Service: Provide on-site installation and comprehensive after-sales support.

Frequently Asked Questions

Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?

Yes, we are one of the professional manufacturers of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment in China. Every machine purchased from our factory has a 12-month warranty after shipment. We offer 12 months for FREE maintenance, with an additional 2 months extension considering sea transportation. If your machine doesn't work, contact us via email or phone. We will diagnose the problem and provide solutions within 24 to 48 hours.

What about the delivery term?

For standard machines in stock: 3-7 working days. For non-stock items: 15-20 working days after payment. Urgent orders receive special arrangements.

Do you accept customization services? Can I have my logo on the machine?

Yes, we offer both standard and customized machines according to your requirements. We provide OEM and ODM services, including placing your logo on the machine.

How can I install and use the machine?

We provide English operation manuals and videos via email. Most machines are shipped fully assembled - simply connect the power cable to begin use. On-site installation assistance is available when necessary.
