Name: UP-6124 Highly Accelerated Aging Test Chamber with Rapid-response Humidification System and Temperature Range +105℃~+132℃
Brand: Dongguan Youbi Test Equipment Co.,Ltd
SKU: UP-6124
Price: 4,799.00 USD
Availability: InStock

Features Gallery Product Description Chat Now

Features

Specifications

Product Name: Hast Test Chamber

Model NO.: UP-6124

HS Code: 8514199000

Temperature Range: +105 ℃~+132℃

Humidity Range: 75% ~100 % RH

Humidity Fluctuation: ≤±3%RH

Control Stability: ±0.3℃;±2%

Pressure Range: 1.2~2.89MPa

Warranty: 1 Year

Additional Service: Support Customer Customization

Size Service: Support Customer Customization

Custom Service: OEM,ODM

Color Service: Support Customer Customization

Specification: Refer To The Actual Size Specifications

Highlight:

Rapid-response Humidification System HAST Test Chamber

Temperature Range +105℃~+132℃ Environmental Test Chamber

Pressure Range 1.2~2.89MPa Highly Accelerated Aging Test Chamber

Basic Infomation

Place of Origin: CHINA

Brand Name: YOUBI

Certification: CE,ISO

Model Number: UP-6124

Payment & Shipping Terms

Packaging Details: Professional Export Wooden Box Packaging

Delivery Time: 5~15 work days

Payment Terms: T/T; D/P; Wester Union; Paypal; Money Gram

Supply Ability: 30 Unit/month

Gallery

UP-6124 Highly Accelerated Aging Test Chamber with Rapid-response Humidification System and Temperature Range +105℃~+132℃

Product Description

UP-6124 Stable Highly Accelerated Aging Test Chamber

This HAST (Highly Accelerated Stress Test) aging chamber features a rapid-response humidification system that significantly reduces humidity testing time for semiconductors. By operating at temperatures above 100°C with increased pressure, it simulates normal humidity tests while maintaining identical failure mechanisms, completing tests in days or weeks instead of months.

Key Advantages

Automatic humidity filling system
Automatic door locking mechanism
Cylindrical workspace accommodates wider sample boards
Hermetic power-pin system for convenient bias testing

Operation Features

Unsaturated or saturated humidity control options
Multi-mode M system (wet bulb/dry bulb) controls humidity during all phases, fully compliant with EIA/JEDEC Test Method A100 & 102C
Touch-screen controller with temperature, humidity, and count-down display including Ethernet Interface
12 specimen power terminals for product testing (24 on double units)
Automatic humidity water filling at test initiation

Cabinet Features

Inner cylinder and door shield prevent specimen dew condensation
Cylindrical interior design maximizes product loading capacity
Two stainless steel shelves included
Integrated casters for easy mobility (except double units)
Push-button door locking system
Bottom storage compartment for peripheral equipment

Safety Features

Overheat and over-pressure protection systems
Door lock safety mechanism prevents opening during pressurization
Specimen power control terminal automatically shuts down product power during alarms

Product Specifications

Temperature Range	Saturated Steam: 100ºC~135ºC Operating Range: 120ºC at 100Kpa / 133ºC at 200Kpa (143ºC available as special order)
Pressure System	Relative pressure: display values on pressure gauge Absolute pressure: gauge value + 100 Kpa (actual inner box value)
Humidity	100% RH saturation steam humidity
Steam Pressure	101.3Kpa + 0.0Kg/cm² ~ 2.0Kg/cm² (3.0Kg/cm² special standard)
Recursive Device	Steam natural convection circulation
Safety Protection	Water short storage protection, over pressure protection with automatic/manual water replenishing and automatic pressure discharge
Accessories	Two layers stainless steel plate
Power Requirements	AC 220V, 1ph 3 Lines, 50/60HZ

Product Images

Our Service Commitment

Consultative Selling Approach

Inquiry Process: Technical requirement discussions, product recommendations, and competitive pricing based on your specific needs.

Customization Process: Detailed drawings and reference photos for customized solutions, final pricing confirmation.

Production & Delivery: Production according to confirmed specifications, progress photos, factory calibration, comprehensive testing, and timely shipping.

Installation & Support: Field installation services and comprehensive after-sales support.

Frequently Asked Questions

Are you a manufacturer? What about warranty and after-sales service?

Yes, we are professional manufacturers of environmental chambers and testing equipment. All machines include 12-month warranty with free maintenance. We extend to 14 months considering sea transportation. Technical support is available via email or video chat with solutions provided within 24-48 hours.

What is your delivery timeline?

Standard machines in stock: 3-7 working days. Custom orders: 15-20 working days after payment. Urgent requirements receive special priority handling.

Do you offer customization and OEM services?

Yes, we provide both standard and fully customized machines according to your specifications, including OEM and ODM services with your logo.

How do I install and operate the equipment?

We provide comprehensive English operation manuals and videos. Most machines ship fully assembled - simply connect power and begin testing. On-site installation assistance is available when needed.
