Walk-in test chamber serves as a test site for large components, assemblies, and finished products in electrical and electronics, aerospace, batteries and automobiles. Our both Static Walk-In Chambers and Dynamic Walk-In Chambers can be configured as a temperature chamber or a temperature humidity chamber.
Walk-in temperature and climate test chambers are especially developed for large test specimens. Size and design are optimized for loading of test specimens. The modular construction and variability in size and equipment is ideal for specific applications.
GB2423/T5170/10586/10592, IEC60068, GJB150, JIS C60068, ASTM D4714, CNS3625/12565/12566
This equipment can simulate different environmental conditions. It's appropriate for testing material performance, such as resistance to heat, dry conditions, humidity, and cold. This enables definition of material performance characteristics.
| Volume | 10m³, 15m³, 20m³, 30m³, 50m³, 100m³ (as per customer requirements) |
|---|---|
| Temperature Range | -70°C to 150°C |
| Humidity Range | 20% to 98% RH |
| Accuracy/Uniformity | ±0.1°C, ±0.1% RH / ±1.5°C, ±5.0% RH |
| Accuracy/Volatility | ±1.0°C, ±2.0% RH / ±0.5°C, ±3.0% RH |
| Cooling Time | 5.0°C/minute |
| Inside Material | SUS#304 Stainless Steel |
| Insulation Material | High-temperature high-density amino acid ethyl ester foam insulation materials |
| Cooling System | Water-cooled / two-stage compressor |
| Protection | No fuse switch, compressor overload switch, high and low pressure protective switch, over-humidity-temperature protective switches, fuses, warning system |
| Accessories | Recorder (option), view window, 50mm diameter testing hole, PL lamp, clapboard, Dry and wet gauze ball |
| Controller | Touch screen programmable controller |
| Compressor | France's Tecumseh Brand or Germany Bitzer |
| Power | 1Φ 220VAC±10% 50/60Hz & 3Φ 380VAC±10% 50/60Hz |
Yes, we are one of the professional manufacturers of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment in China. Every machine purchased from our factory has 12 month warranty after shipment. Generally, we offer 12 months for FREE maintenance. While considering sea transportation, we can extend 2 months for our customers.
Moreover, if your machine doesn't work, you can send us an e-mail or call us. We will try our best to find the problem through our conversation or by video chat if necessary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.
For our standard machine which means normal machines: If we have stock in the warehouse, delivery is 3-7 working days; If there is no stock, normally, the delivery time is 15-20 working days after payment is received; If you are in urgent need, we will make a special arrangement for you.
Yes, of course. We can not only offer standard machines but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.
Once you have ordered the testing machines from us, we will send you the operation manual or video in English version through Email. Most of our machines are shipped as a complete unit, which means it is already installed. You just need to connect the power cable and start to use it. And if it's necessary, we can also assist you to install your machine on-site.
