Fully Sealed Dustproof Test Chamber with Multi-Directional Blowing System for IP5X and IP6X Testing

1 Unit
MOQ
Negotiable
Price
Fully Sealed Dustproof Test Chamber with Multi-Directional Blowing System for IP5X and IP6X Testing
Features Gallery Product Description Chat Now
Features
Specifications
Product Name: Dustproof Test Chamber
Temperature Range: Rt+5℃~35℃
Dust Flow Rate: 1.2~11m/S
Nominal Line Diameter: 50um
Nominal Line Spacing: 75um
Warranty: 1 Year
Highlight:

Fully Sealed Dustproof Test Chamber

,

Multi-Directional Blowing System Environmental Test Chamber

,

IP5X and IP6X Testing Dust Protection Level Test Chamber
Basic Infomation
Place of Origin: CHINA
Brand Name: YOUBI
Certification: CE,ISO
Model Number: UP-6316
Payment & Shipping Terms
Packaging Details: Professional Export Wooden Box Packaging
Delivery Time: 5-15 work days
Payment Terms: T/T,D/P,Western Union,Paypal,Money Gram
Supply Ability: 30 Unit/month
Product Description
Fully Sealed Industrial Dustproof Test Chamber with Multi-Directional Blowing System
Product Overview

This fully sealed industrial dustproof test chamber simulates the destructive effects of natural wind and sand climate on products and is specifically designed for testing the seal performance of product enclosures. The equipment is engineered to test IP5X and IP6X protection grades as specified in enclosure protection standards.

Key Features
  • Independent control of F1, F2, and F3 conditions via panel controls with powerful dust spraying device
  • Vibration equipment ensures consistent dust concentration during each spraying cycle
  • Precision dust concentration collector minimizes operational estimation errors
  • Dust and sand sharing capability
  • Vertical air circulation system with dust recycling capability
  • Advanced stainless steel ductwork with tapered hopper interface
  • Single high-power, low-noise centrifugal fan with adjustable wind speed
  • Forms "O" type closed-loop system for optimal air flow and dust dispersion
Compliance Standards

IEC 60529, GB2423.37, GB4706, GB 4208, GB 10485, GB 7000.1, GJB 150.12, DIN

Technical Specifications
Parameter UP-6316-A UP-6316-B
Inner Size (mm) 800 × 800 × 800 1000 × 1000 × 1000
Test Species Talcum powder
Duration Time 2 hours or 8 hours
Test Temperature RT ~ 7°C
Test Humidity 45% - 75% RH
Nominal Diameter of Metal Screen Mesh 50μm
Nominal Spacing Between Lines 75μm
Wind Speed ≥ 2 m/s
Dust Concentration 2 ~ 4 Kg/m³
Dust Requirements Meets JIS6 requirement (or national standards)
Oscillator Period 0 - 99H 99M 99S
Blowing Dust Set Continuous and periodic dusting time determined arbitrarily
External Material High quality cold rolled steel sheet electrostatic spraying
Inner Material SUS304 precision welding of quality stainless steel plate
Thermal Insulation Material Ultrafine glass fiber cotton
Safety Protection Overtemperature and overlimit alarm protection, power leakage, short circuit, lack of phase protection, undervoltage protection
Power AC220/380V ±10%, 1PH, 50/60HZ
Standard Configuration Vacuum pump one, gas flowmeter, air source excuse, pressure gauge, oil and water separator
Product Images
Fully Sealed Dustproof Test Chamber with Multi-Directional Blowing System for IP5X and IP6X Testing 0 Fully Sealed Dustproof Test Chamber with Multi-Directional Blowing System for IP5X and IP6X Testing 1
Our Service Commitment
Customer Inquiry Process

We discuss testing requirements and technical details, suggest suitable products, and provide competitive pricing based on customer specifications.

Specifications Customization Process

We create detailed drawings for custom requirements, provide reference photos, and confirm final solutions and pricing with customers.

Production and Delivery Process

Machines are manufactured to confirmed specifications with progress photos provided. We conduct factory or third-party calibration, complete testing, and arrange secure packaging and timely delivery.

Installation and After-Sales Service

We provide field installation services and comprehensive after-sales support to ensure optimal performance.

Frequently Asked Questions
Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?

Yes, we are professional manufacturers of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment. Every machine includes a 12-month warranty after shipment, with 12 months of free maintenance. Considering sea transportation, we extend this to 14 months for international customers. If your machine requires service, contact us via email or phone. We diagnose issues through conversation or video chat and provide solutions within 24-48 hours.

What about the delivery term?

Standard machines in stock: 3-7 working days. Custom orders: 15-20 working days after payment. Urgent requirements receive special priority scheduling.

Do you accept customization services? Can I have my logo on the machine?

Yes, we offer both standard and fully customized machines according to your requirements. We provide OEM and ODM services, including applying your logo to the equipment.

How can I install and use the machine?

We provide comprehensive English operation manuals and videos. Most machines are shipped fully assembled - simply connect the power cable to begin operation. On-site installation assistance is available when necessary.
