Home /Products/Universal Testing Machine/Computer Servo Universal Testing Machine UP-2003 for Metal Rubber Plastic Peel Compression Bend Test

Computer Servo Universal Testing Machine UP-2003 for Metal Rubber Plastic Peel Compression Bend Test

1 Unit
MOQ
Negotiable
Price
Computer Servo Universal Testing Machine UP-2003 for Metal Rubber Plastic Peel Compression Bend Test
Features Gallery Product Description Chat Now
Features
Specifications
Load Range: 1~50kN (100-5000kg Optional)
Test Speed: 0.1~500mm/min Adjustable
Speed Accuracy: ±1% (Class 1)
Force Resolution: 1/100,000
Effective Stroke: 800mm (Customizable)
Effective Width: 400mm (Customizable)
Control Mode: Computer Servo Control
Acquisition Module: 24-bit High Resolution
Power Source: AC110-220V
Unit Selection: KG, N, KN, LBF
Highlight:

Computer Servo Universal Testing Machine

,

Metal Rubber Plastic Universal Testing Machine

,

UP-2003 Universal Testing Machine
Basic Infomation
Place of Origin: CHINA
Brand Name: YOUBI
Certification: CE,ISO
Model Number: UP-2003
Payment & Shipping Terms
Packaging Details: Professional Export Wooden Box Packaging
Delivery Time: 5-15 work days
Payment Terms: T/T,D/P,Western Union,Paypal
Supply Ability: 30 Unit/month
Product Description
Computer Servo Double Column Universal Tensile Testing Machine Model UP-2003

Our double column servo universal tensile testing machine is designed for tensile, compression, peel, shear, tear and bending tests. It is widely used to test metal, rubber, plastic, textile, leather, shoe materials and other raw materials & finished products.
The equipment complies with international test standards including ASTM D638, ASTM E8, ISO 6892, etc. Suitable for quality inspection laboratories, research institutes and manufacturing factories.

Universal tensile testing machine back view, servo double column UTM lab test equipment structure

Main Features:

  1. High precision servo motor and drive system, stable running and accurate test data
  2. 24-bit high-resolution acquisition module, test result repeatability
  3. Computer control, professional test software, automatically generate test curve & report
  4. Multiple safety protection: overload protection, limit stop, emergency stop button
  5. Modular fixture design, easy to change different jigs for various material tests
  6. Heavy-duty aluminum alloy double column frame, durable and low noise

Tensile fixture and load cell close-up detail of double column universal tensile testing machine


Technical Specifications:

Item Parameter
Load Capacity 50kg ~ 5000kg optional
Force Resolution 1/100000
Test Speed 0.1 ~ 500 mm/min adjustable
Effective Stroke 800mm (custom available)
Effective Width 400mm
Control Mode Computer servo control
Standards ASTM D638, ASTM E8, ISO 6892


Technical specification table of computer servo universal tensile testing machine UP-2003

Machine Structure & Detail:

Solid cabinet base with adjustable foot casters, easy to move and level the machine on lab ground. Independent control panel with emergency stop button for safe operation.

Adjustable caster and base cabinet detail of universal tensile testing machine for laboratory

Application Fields:

  • Plastic & Rubber Industry
  • Metal Material Factory
  • Textile & Non-woven Fabric
  • Shoe & Leather Products
  • Packaging & Composite Materials
  • Research & QC Laboratory

Our Service:

  • Factory direct supply, competitive price
  • Custom load capacity, stroke and fixtures
  • English operation software & user manual
  • 12 months warranty, lifetime technical support
  • Professional pre-sales test solution recommendation


Send inquiry now to get quotation and test solution!


FAQ:
1. Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
Yes, we are the one of professional manufacturers of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment... in China. Every machine purchased from our factory has 12 month warranty after shipment. Generally, we offer 12 months for FREE maintenance. while considering sea transportation, we can extend 2 months for our customers.
Moreover, If your machine doesn't work, you can send us an e-mail or call us we will try our best to find the problem through our conversation or by video chat if necessary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.
2. What about the delivery term?
For our standard machine which means normal machines, If we have stock in the warehouse, is 3-7 working days;
If there is no stock, normally, the delivery time is 15-20 working days after payment is received;
If you are in urgent need, we will make a special arrangement for you.
3. Do you accept customization services? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.
4. How can I install and use the machine?
Once you have ordered the testing machines from us, we will send you the operation manual or video in English version through Email.
Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use it. And if it's necessary, we can also assist you to install your machine on-site.
