Name: IPX9K High Pressure Steam Jet Cleaning Environmental Test Chamber with Adjustable Water Spray Temperature and Four Spray Nozzles
Brand: Dongguan Youbi Test Equipment Co.,Ltd
SKU: UP-6300
Price: 4,799.00 USD
Availability: InStock

Features Gallery Product Description Chat Now

Features

Specifications

Product Name: Waterproof Test Chamber

Model NO.: UP-6300

Water Spray Temperature: Ambient ~ 88ºC (Adjustable)

Water Spray Angel: 0°,30°,60°,90°

Spray Nozzle: Four, 30 Seconds Each Position

Water Pressure: 8000-10000 Kpa (adjustabl)

Water Flow Rate: 14L-16L/min

Spray Range: 30° ± 5°(Single Hole); Space 100-150mm

Testing Platform Speed: 5 ±1 R.p.m

Warranty: 1 Year

Custom Service: OEM,ODM

Specification: Refer To The Actual Size Specifications

Highlight:

High Pressure Steam Jet Cleaning IPX9K Test Chamber

Adjustable Water Spray Temperature Water Spray Test Chamber

Four Spray Nozzles Environmental Test Chamber

Basic Infomation

Place of Origin: CHINA

Brand Name: YOUBI

Certification: CE,ISO

Model Number: UP-6300

Payment & Shipping Terms

Packaging Details: Professional Export Wooden Box Packaging

Delivery Time: 5~15 work days

Payment Terms: T/T; D/P; Wester Union; Paypal; Money Gram

Supply Ability: 30 Unit/month

Gallery

IPX9K High Pressure Steam Jet Cleaning Environmental Test Chamber with Adjustable Water Spray Temperature and Four Spray Nozzles

Product Description

IPX9K High Pressure Steam Jet Cleaning Water Spray Climatic Test Chamber

The High Pressure Steam Jet Cleaning Water Spray IPX9K Climatic Test Chamber is designed to inspect IEC enclosures for electrical equipment (IP supplementary code test). This equipment is specifically applicable for waterproof testing of electrical and automotive components under high temperature and high pressure conditions. Scientifically engineered to realistically simulate water spray environments.

Compliance Standards

IEC60529, GB4208, DIN40050-9, ISO20659, EN 60529, DIN 40050-9

Key Features

Applicable to IPX8 waterproof rating testing
Constructed with 304 stainless steel tank body, high-precision overall sub-arc welding for excellent pressure bearing capacity
Square external structure with stainless steel plate welding, user-friendly 45° bevel design with button operation
Top cover secured with 8 sets of ring screws (distribution auxiliary steel bars)
Equipped with safety valve for automatic pressure release when exceeding rated pressure

Technical Specifications

Model	UP-6300
Product Name	High Pressure Steam Jet Cleaning Water Spray IPX9K Climatic Test Chamber
Internal Dimensions (mm)	100012001000 DWH
Overall Dimensions (mm)	125017002050 DWH
Water Spray Temperature	Ambient ~ 88°C (Adjustable)
Water Spray Angle	0°, 30°, 60°, 90°
Spray Nozzle	Four nozzles, 30 seconds each position
Spray Range	30° ± 5° (Single hole); Space 100-150mm
Spray Distance to Specimens	10-15cm
Water Pressure	8000-10000 Kpa (Adjustable)
Water Flow Rate	14-16L/min
Testing Platform Speed	5 ±1 r.p.m
Test Platform Height	200-450mm, Adjustable
Test Platform Diameter	600mm
Maximum Load	≤100kg
Controller	Programmable color LCD touch screen controller with PC Link software, RS-232 interface
Safety Features	Power protection, timing auto-stop, water protection, motor overheating protection, water temperature overheating automatic drainage
Temperature Sensor	PTR Platinum Resistance PT100Ω/MV A-class
Heater	Nichrome heater
Interior Material	SUS304 stainless steel
Exterior Material	Steel Plate with protective coating
Power Supply	380V 50HZ, Three-phase five-wire
Operating Environment	Grading, no corrosive gas, avoid direct sunlight; Temperature: +5~+35°C; Humidity: 45~85%RH

Our Comprehensive Service

Customer Inquiry: Technical consultation, requirement analysis, and product recommendation with competitive pricing
Custom Specifications: Detailed drawings, reference photos, and final solution confirmation
Production & Delivery: Transparent production process with progress photos, factory calibration, and timely shipping
Installation & Support: Professional installation services and comprehensive after-sales support

Frequently Asked Questions

Are you a manufacturer? What about warranty and after-sales service?
Yes, we are professional manufacturers of environmental chambers and testing equipment. All machines include 12-month warranty with free maintenance. Extended support available for international shipping. Technical support provided via email, phone, or video chat with solutions within 24-48 hours.
What is the delivery time?
Standard machines: 3-7 working days (in stock) or 15-20 working days (custom orders). Urgent requirements accommodated with special arrangements.
Do you accept customization and branding?
Yes, we offer comprehensive OEM and ODM services including custom specifications and logo application.
How is installation handled?
Most machines ship fully assembled with English operation manuals and videos. Basic power connection required. On-site installation assistance available when necessary.
