Home /Products/Packaging Testing Equipment/2000KGF Capacity Compression Tester and Stacking Tester with Servo Motor Drive Compliant with ISO 2872 Standards

2000KGF Capacity Compression Tester and Stacking Tester with Servo Motor Drive Compliant with ISO 2872 Standards

1 Unit
MOQ
Negotiable
Price
2000KGF Capacity Compression Tester and Stacking Tester with Servo Motor Drive Compliant with ISO 2872 Standards
Features Gallery Product Description Chat Now
Features
Specifications
Product Name: Pressure Tester And Stacking Tester
Product Name: Packaging Testing Equipment
Model NO.: UP-6035
Additional Service: Support Customer Customization.
Delivery Terms: CIF, DDP, DDU, FedEx, DHL, FOB
Transport Package: Professional Export Wooden Carton Packaging
Capacity: 2000KGF
Resolution: 1/100,000
Force Accuracy: ≤0.5%
Highlight:

ISO 2872 Packaging Testing Equipment

,

ISO 2872 2874 Packaging Testing Machine

,

Pressure Tester And Stacking Tester UP-6035
Basic Infomation
Place of Origin: CHINA
Brand Name: YOUBI
Certification: CE,ISO
Model Number: UP-6035
Payment & Shipping Terms
Packaging Details: Professional export packing
Delivery Time: 5-15 work days
Payment Terms: D/P,T/T,Western Union,Paypal
Supply Ability: 30 Unit/month
Product Description
Carton Compression Tester and Stacking Tester During Transportation - ISO 2872 Standards UP-6035
Product Overview

Compression Tester and Stacking Tester During Transportation designed to meet ISO 2872 Standards UP-6035 requirements for comprehensive packaging testing.

Design Standards

TAPPI-T804, JIS-Z0212, ISO2872, NF H13-001, CNS 2236/3511, ASTM D642

Testing Capabilities
  • Strength Test: Measures maximum compression force and displacement of corrugated boxes, containers, and packaging materials
  • Constant/Fixed Test: Set specific compression force and displacement parameters to evaluate box performance and provide essential design data (also known as load-keeping test)
  • Stacking Test: Conduct stacking tests under various conditions as per standard requirements, including 12-hour and 24-hour durations
Key Features
  • Windows-based platform with intuitive dialog box parameter settings
  • Single-screen operation eliminates screen switching
  • Multi-language support: Simplified Chinese, Traditional Chinese, and English
  • Translational and overlapping modes for comprehensive curve data comparison
  • Multiple measurement units with imperial and metric system switching
  • Automatic magnification function for optimal graphic display
  • Advanced machine structure with strong rigidity, compact size, and lightweight design
  • Comprehensive testing capabilities: compression strength, stack strength, and peak value measurement
Technical Specifications
Capacity 2000 KGF
Resolution 1/100,000
Units kg, lb, N, g (switchable)
Force Accuracy ≤0.5%
Test Space L800×W800×H800mm, 1000×1000×1000mm (Customizable)
Drive System Servo Motor
Test Speed 0.1~500mm/min (Standard: 10±3mm/min)
Dimensions 1600×1200×1700mm
Weight 500kg
Power 1φ, 220V/50Hz
Control Full computer software control
Safety Features High precision sensor, ball screw, overload protection, fault alarm, limit stroke protection
Product Images
Compression test machine for material compressive strength testing Compression test machine for carton compressive strength testing
Our Service Process
  • Customer Inquiry: Technical discussion, requirement analysis, product recommendation, and competitive pricing
  • Customization: Detailed drawings, reference photos, and final solution confirmation
  • Production & Delivery: Quality production with progress updates, calibration services, and timely shipping
  • Installation & Support: Field installation and comprehensive after-sales service
Frequently Asked Questions
Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
Yes, we are professional manufacturers of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment. Every machine includes a 12-month warranty after shipment with free maintenance. Considering sea transportation, we extend an additional 2 months for international customers. For technical issues, contact us via email or phone - we provide solutions within 24-48 hours.
What about the delivery term?
Standard machines in stock: 3-7 working days. Out-of-stock items: 15-20 working days after payment. Urgent requirements receive special priority handling.
Do you accept customization services? Can I have my logo on the machine?
Yes, we offer both standard and customized machines according to your specifications. We provide OEM and ODM services including custom branding and logo placement.
How can I install and use the machine?
We provide comprehensive English operation manuals and videos. Most machines ship fully assembled - simply connect power and begin operation. On-site installation assistance available when necessary.
