Product Details:
Payment & Shipping Terms:
|
| Model Number: | HTF-007 | Iterm: | Fabric Pilling Tester |
|---|---|---|---|
| Minimum Order Quantity: | 1 Set | Delivery Time: | 15 Working Days |
| Payment Terms: | T/T, L/C, Western Union | Place Of Origin: | Guangdong,China(Mainland) |
| STANDARD: | GB/T4802.1-2008, DIN 53863.2 | ||
| High Light: | DIN 53863.2 Fabric Pilling Tester,DIN 53863.2 Fabric Pilling Tester Machine |
||
To determine the pilling and fuzzing characteristics of textile fabrics. chemical fiber, blended, knitting, woven fabrics.
Standard: GB/T4802.1-2008, DIN 53863.2
Specifications
| Pilling trajectory | circular track of 40mm diameter |
| Brush with adjustable height | 2~12mm |
| Chemical Fiber fabric | 590cN |
| Combed wool fabric | 780cN |
| Crude wool fabric | 490cN |
| Specimen size | 112.8mm with area 100cm2 |
| Rubbing times | 1~9999 |
| Rubbing speed | 60 RPM |
| Power | AC220V 50Hz 60W |
| Dimension | 540*250*345 mm (L*W*H) |
| Weight | 35KG |
| Standard | GB/T4802.1-2008, DIN 53863.2 |
| Accessories | power line 1pcs |
