UP-6300-S IPX1~IPX6 Water Spray Test Chamber IEC 60529 IP Water Spray Environmental Chamber with SUS304 Stainless Steel

1 Unit
MOQ
Negotiable
Price
UP-6300-S IPX1~IPX6 Water Spray Test Chamber IEC 60529 IP Water Spray Environmental Chamber with SUS304 Stainless Steel
Features Gallery Product Description Chat Now
Features
Specifications
Internal Dimensions: 900×900×900 Mm / 1400×1400×1400 Mm
Overall Dimensions: 1020×1360×1560 Mm / 1450×1450×2000 Mm
Volume: 512L / 1728L
Drip Tray Size: 300×300 Mm / 600×600 Mm
Oscillating Tube Radius: 350 Mm / 600 Mm
Spraying Hole Diameter: φ0.4 Mm
Oscillating Tube Range: ±45°, ±60°, ±90°, ±180°
Turntable Rotation Speed: 1r/min, Adjustable
Interior Material: SUS304 Stainless Steel
Exterior Material: Steel Plate With Protective Coating
Chamber Volume: 512 L / 1728 L
Turntable Speed: 1 R/min, Adjustable
Power Supply: 380 V, 50 Hz, 4 A
Rated Power: 2.0 KW
Sample Power Supply: 220 V
Customized Support: ODM,OEM
Warranty: 1 Year
Highlight:

Laboratory IP Water Spray Test Chamber

,

UP-6300 Water Spray Test Chamber

,

Water Spray Test Chamber IEC60529
Basic Infomation
Place of Origin: CHINA
Brand Name: YOUBI
Certification: CE,ISO
Model Number: UP-6300-S
Payment & Shipping Terms
Packaging Details: Professional Export Wooden Box Packaging
Delivery Time: 5-15 work days
Payment Terms: T/T,D/P,Western Union,Paypal
Supply Ability: 30 Unit/month
Product Description
Product Overview

The UP-6300-S IPX1–IPX6 water spray test chamber is engineered in accordance with the IEC 60529 standard for IP ingress protection and waterproof testing. It simulates a range of rain and spray conditions from IPX1 through IPX6, making it suitable for electronic, automotive, and lighting products. The chamber is laboratory grade and fully customizable.

Quick Reference
Item Value
Model UP-6300-S
Test grades IPX1, IPX2, IPX3, IPX4, IPX5, IPX6
Compliance IEC 60529:2013
Power supply 380 V, 50 Hz, 4 A
Rated power 2.0 kW
Sample power supply 220 V
Warranty 12 months (whole machine)
Lead time 7–15 working days
Port of loading Guangzhou / Shenzhen
Technical Specifications
Name IP Water Spray Environmental Chamber IEC 60529
Model UP-6300-S-90
Internal dimensions (mm) 900 * 900 * 900
Overall dimensions (mm) 1020 * 1360 * 1560
Volume 512 L
Drip tray size 300 * 300 mm
Oscillating tube radius 350 mm
Spraying hole diameter φ0.4 mm
Oscillating tube range ±45°, ±60°, ±90°, ±180° (theoretical value)
Turntable rotation speed 1 r/min, adjustable
Controller Programmable color display touch screen controller
Water pressure control Flow meter
Water supply system Built-in water tank, automatic water supply, water purification system
Exterior material Steel plate with protective coating
Interior material SUS304 stainless steel

Note: The UP-6300-S series is also available in a larger UP-6300-S-140 configuration with 1400 * 1400 * 1400 mm internal dimensions, 1728 L volume, 600 * 600 mm drip tray, and 600 mm oscillating tube radius.

Product Gallery
UP-6300-S IPX1 to IPX6 water spray test chamber with programmable touch screen controller and stainless steel interior
Close-up of the oscillating tube and spray nozzles used for IPX3 and IPX4 water spray testing
Laboratory IP water spray environmental chamber IEC 60529 for IPX3 and IPX4 ingress protection testing
